Xerox Phaser 6125 Service Manual

3-60 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
Load Tray/Tray Empty
No paper detected in tray.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
Left Side Harness Assy (PL3.1.18)
Photo Sensor (PL3.2.13)
Paper Feeder (PL3.1.3)
MCU Board (PL8.2.13)
■ “Map 2 - Laser Unit, Feeder Assembly”
on page 10-9
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Feeder, Manual Feed, & Registration” on
page 10-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the paper for loading and
setting
Check that the paper in use meets the
print job requirements
Does the error still occur after
reloading the paper and changing the
paper settings that the print job
requires?
Go to step 2. Complete
2 Check the No Paper Actuator for shape
and operation
Pull the paper tray out.
Are the shape and operation of the No
Paper Actuator normal?
Go to step 3. Reseat the No
Paper Actuator.
If broken or
deformed,
replace the
Feeder
Assembly
(page 8-25).
3 Check the Tray No Paper Sensor
(Photo Sensor) for operation
Pull the CASSETTE ASSY 250 out.
Perform the Tray No Paper test
(page 4-26): Service Mode > Engine
Diag > Sensor Test > Tray No Paper
Does the number on the screen
increase by one, when the actuator of
the Tray No Paper Sensor (Photo
Sensor) is operated?
Replace the
MCU Board
(page 8-59).
Go to step 4.
4 Check the connectors of the Tray No
Paper Sensor (Photo Sensor) for
connection
Check the connections between the
MCU Board and Photo Sensor.
Are P/J23 and P/J234 connected
correctly?
Go to step 5. Reconnect the
connector(s) P/
J23 and/or P/
J234 correctly.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
