Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 1-3
General Information
Printer Configurations
The printer is available in these configurations.
Printer Configurations
Features
Printer Configuration
6130N (PDL) 6125N (GDI)
Processor and Clock Speed 400 MHz 400 MHz
Memory Configuration
a
a. The Phaser 6125/6130 has one memory slot supporting 256 MB/ 512 MB/ 1 GB DDR2
DIMMs, to a maximum of 1152 MB. Standard memories are soldered on board. The
Phaser 6125 does not accept additional memory.
128 MB 64 MB
Print Speed (Color/Mono) 12/16 12/16
Resolutions (dpi)
Standard 600 x 600 x 1 bit 600 x 600 x 1 bit
Enhanced 600 x 600 x 4 bit 600 x 600 x 4 bit
Adobe PostScript 3 Fonts Standard Standard
PCL6 Fonts Standard Standard
Job Pipelining Standard Standard
USB 2.0 Hi-Speed Support Standard Standard
Ethernet Interface 10/100 Base-TX 10/100 Base-TX
Manual Feed Slot (Single sheet) Standard Standard
Standard Tray (250 Sheet) Standard Standard
Wireless LAN Optional Optional
Warranty 1 year onsite 1 year onsite

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
