Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-71
Error Messages and Codes
Imaging Unit Errors
Replace Imaging Unit/PHD CRUM Error
Applicable Chain Link
■ 091-916: Imaging Unit CRUM Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL8.2.13
■ Imaging Unit, PL4.1.21
■ “Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser” on
page 10-8
■ “Map 3 - LVPS, Drive Motors, I/P Board,
AC Power” on page 10-10
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Imaging Unit type
Is the correct Imaging Unit installed?
Go to step 3. Replace with the
correct Imaging
Unit, then go to
step 2.
2 Does the error still occur when the
power is turned OFF and ON?
Go to step 3. Complete
3 Reseat the Imaging Unit.
Does the error still occur when the
power is turned OFF and ON?
Go to step 4. Complete
4 Check the connectors to the MCU
Board and Imaging Unit.
Are P/J42 and P/J422 connected
correctly?
Go to step 6. Reconnect the
connector(s) P/
J42 and/or P/
J422 securely,
then go to step
5.
5 Does the error still occur when the
power is turned OFF and ON?
Go to step 6. Complete
6 Replace the Imaging Unit (page 8-8).
Does the error still occur when the
power is turned OFF and ON?
Replace the
MCU Board.
(page 8-59)
Complete

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
