Xerox Phaser 6125 Service Manual

3-78 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
Other Errors
Invalid Job
Error occurs when the configuration of the printer does not match the printer
driver.
Applicable Chain Link
■ 016-799: Invalid Job (Job Environment Violation)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL8.1.9
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the paper size. Does the paper
meet the specifications?
Go to step 2. Replace the
paper.
2 Check the paper size setup on the
Control Panel: Menu > Tray Settings >
Paper Size.
Go to step 4. Go to step 3.
3 Set the paper size in the Control Panel
to match the paper in the tray. Does
the error still occur?
Replace the
Processor Board
(page 8-60).
Complete.
4 Does the error still occur? Replace the
Processor Board
(page 8-60).
Complete.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
