3-66 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
Motor Errors
Fan Motor Error
The Fan Motor is not in operation.
Applicable Chain Link
■ 042-313: Fan Motor Error
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL8.2.13
■ LVPS Harness Assy, PL9.1.3
■ FAN, PL8.1.1
■ LVPS Board, PL8.2.1
■ “Map 1 - Transfer Unit, Control Panel,
Imaging Unit, Dispenser, Fuser” on
page 10-8
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “DC Power Supply” on page 10-17
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Perform the Fan test (page 4-31):
Service Mode > Engine Diag > Fan
HIGH.
Does the Fan operate properly?
Replace the
MCU Board.
(page 8-59)
Go to step 2.
2 Check the connection between the FAN
and LVPS.
Is P/J503 on the LVPS connected
correctly?
Go to step 4. Reconnect the
connector P/
J503 correctly,
then go to step
3.
3 Does the error still occur when the
power is turned OFF and ON?
Go to step 4. Complete
4 Check the connections between the
LVPS and MCU Board.
Are P/J501 and P/J14 connected
correctly?
Go to step 6. Reconnect the
connector(s) P/
J501 and P/J14
correctly, then
go to step 5.
5 Does the error still occur when the
power is turned OFF and ON?
Go to step 7. Complete

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
