Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 10-15
Plug/Jack and Wiring Diagrams
Print Engine Wiring Diagrams
Wiring Diagrams Configurations
Wiring Diagram Description
DC Power Supply Connections of LVPS with MCU Board.
Connections of Power Switch with LVPS.
Connections of GFI Breaker with Power Switch.
Connections of Main Fan with LVPS.
Connections of Interlock Harness with LVPS.
Connections of RH Cover Switch with MCU Board.
Feeder, Manual
Feed, &
Registration
Connections of Feed Solenoid with MCU Board.
Connections of Registration Sensor with MCU Board.
Connections of Manual Feed (SSI) No Paper Sensor with
MCU Board.
Connections of CST No Paper Sensor with MCU Board.
Connections of Drive Clutch with MCU Board.
Drive Connections of Feeder Drive with MCU Board.
Connections of Main Drive with MCU Board.
Connections of Sub-Drive with MCU Board.
Laser Unit (ROS) Connections of Laser Unit with MCU Board.
Xerographic Connections of EEPROM Board with MCU Board.
Connections of Imaging Unit (PHD) with MCU Board.
Connections of Humidity/Temperature Sensor with MCU
Board.
Connections of Erase LEDs and MCU Board.
Connections of Transfer Unit with MCU Board.
High Voltage Connections of HVPS with MCU Board.
Developer Connections of Dispenser Motor (Y) with MCU Board.
Connections of Dispenser Motor (M) with MCU Board.
Connections of Dispenser Motor (C) with MCU Board.
Connections of Dispenser Motor (K) with MCU Board.
Connections of CRUM Connector (Y) with MCU Board.
Connections of CRUM Connector (M) with MCU Board.
Connections of CRUM Connector (C) with MCU Board.
Connections of CRUM Connector (K) with MCU Board.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
