Phaser 6125/6130 Color Laser Printer Service Manual 8-3
Service Parts Disassembly
Standard Orientation of the Printer
When needed, the orientation of the printer is called out in the procedure as
an aid for locating the printer parts. The following figure identifies the Front,
Rear, Left, and Right sides of the printer.
s6130-051
Rear
Left
Right
Front
