3-42 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
Jam at Front Cover
No Paper condition detected at the Manual Feed.
Initial Actions
■ Check the paper path for obstructions or debris.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Left Side Harness Assy (PL3.1.18)
■ Photo Sensor (PL3.2.13)
■ MCU Board (PL8.2.13)
■ “Map 2 - Laser Unit, Feeder Assembly”
on page 10-9
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “Feeder, Manual Feed, & Registration” on
page 10-19
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the customer operation
Did the customer insert the paper to
the Manual Feed Slot during print?
After print
completion,
insert the paper
to the SSI.
Go to step 2.
2 Check the Manual Feed No Paper
Sensor (Photo Sensor) for operation
Perform the Manual Feed Sensor test
(page 4-25): Service Mode > Engine
Diag > Sensor Test > Manual Feed
Sensor.
Does the number on the screen
increase by one, when the actuator
(SSI Actuator) is operated by paper.
Go to step 3. Go to step 4.
3 Check the error
Does the error still occur when
printing?
Replace the
MCU Board
(page 8-59).
Complete
4 Check the connections between the
MCU Board and Manual Feed No Paper
Sensor (Photo Sensor).
Are P/J23 and P/J233 connected
correctly?
Go to step 6. Reconnect the
connector(s) P/
J23 and/or P/
J233 correctly,
then go to step
5.
5 Does the error still occur when
printing?
Go to step 6. Complete
