Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-41
Error Messages and Codes
27 Check the power to the Drive Clutch
Assy
Disconnect J26 from the MCU Board.
Is the voltage across P26-4pin <=>
ground on the MCU Board, about +24
VDC when the Interlock Switch (HARN
ASSY INTERLOCK) is pushed?
Go to step 28. Replace the
MCU Board
(page 8-59).
28 Check the Drive Clutch Assy for
resistance
Disconnect P/J262 of the Drive Clutch
Assy.
Is the resistance across J262-1 and
J262-2 approximately 280-ohm?
Replace the
MCU Board
(page 8-59).
Replace the
Drive Clutch Kit.
(page 8-21)
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
