Xerox Phaser 6125 Service Manual

3-40 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
20 Check the Manual Feed No Paper
Sensor (Photo Sensor) for operation
Check the voltage across J23-8pin <=>
ground on the MCU Board.
Does the voltage change, when the SSI
Actuator is operated?
Replace the
MCU Board
(page 8-59).
Replace the
Feeder
Assembly
(page 8-25).
21 Check the connectors of the Regi
Sensor (Photo Sensor) for connection
Check the connections between the
MCU Board and Regi Sensor (Photo
Sensor).
Are P/J23 and P/J232 connected
correctly?
Go to step 22. Reconnect the
connector(s) P/
J23 and/or P/
J232 correctly.
22 Check the Left Side Harness Assy for
continuity
Disconnect J23 from the MCU Board.
Disconnect J232 from the Regi Sensor
(Photo Sensor).
Is each cable of J23 <=> J232
continuous?
Go to step 23. Replace the
Feeder Assy
(page 8-25) or
Left Side
Harness Assy
(page 8-26).
23 Check the power to the Regi Sensor
(Photo Sensor)
Disconnect J23 from the MCU Board.
Is the voltage across P23-3pin <=>
ground on the MCU Board about +3.3
VDC?
Go to step 24. Replace the
MCU Board
(page 8-59).
24 Check the Regi Sensor (Photo Sensor)
for operation
Check the voltage across J23-5pin <=>
ground on the MCU Board.
Does the voltage change, when the
Regi Roll Actuator is operated?
Replace the
MCU Board
(page 8-59).
Replace the
Feeder
Assembly
page 8-25.
25 Check the connectors of the Drive
Clutch Assy (Regi Clutch) for
connection
Check the connections between the
MCU Board and Drive Clutch Assy.
Are P/J26 and P/J262 connected
correctly?
Go to step 26. Reconnect the
connector(s) P/
J26 and/or P/
J262 correctly.
26 Check the HARN ASSY KSNR REGCL
for continuity
Disconnect J26 from the MCU Board.
Disconnect P262 from the Drive
Clutch Assy (Regi Clutch).
Is each cable of J26 <=> P262
continuous?
Go to step 27. Replace the
HARN ASSY
KSNR REGCL.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
