Phaser 6125/6130 Color Laser Printer Service Manual 8-5
Service Parts Disassembly
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
b. Fuser (page 8-9).
7. Open the Toner Access Door.
8. Remove the Toner Cartridges (page 8-10).
Names of parts that appear in the removal and replacement procedures
may not match the names that appear in the Parts List. For example, a
part called the Registration Chute Assembly in a removal procedure may
appear on the Parts List as Assembly, Registration Chute. When working
on a removal procedure, ignore any prerequisite procedure for parts
already removed.
Many parts are secured by plastic tabs. DO NOT over flex or force these
parts. DO NOT over torque the screws threaded into plastic parts.
Unplug the AC power cord from the wall outlet before removing any
printer part.
Notations in the Disassembly Text
■ The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
■ The notation “PLX.X.X” indicates that this component is listed in the Parts
List.
■ Bold arrows in an illustration show direction of movement when removing
or replacing a component.
■ The notation “(tap, plastic, 10 mm)” or “(metal, 6 mm)” refer to the type of
screw being removed.
Provides information specific to the replacement of parts or
assemblies.
