Phaser 6130 Color Laser Printer Service Manual A-3
Reference
Firmware Update
Boot Controller Update
Note
Boot Code can be updated via USB port only.
1. Down load applicable files from the Xerox support web site.
2. Turn off the printer.
3. Ensure your USB cable is connected.
4. Press the Up Arrow, Down Arrow, and Menu buttons simultaneously
and turn on the printer.
5. The FW Update Password is displayed.
6. Press the Down Arrow button 2 times.
7. Press the OK button.
8. The F/W Download is displayed.
9. Select DL Mode USB. Press the OK button.
10. The serial number of the printer is displayed. Then the DownLoad Mode
Send F/W Data is displayed.
11. On your computer, locate the downloaded file. Open the Boot directory.
Double-click the Xeroxfwup.exe file.
12. Select USB. Click the Next button.
13. The xeroxfwup window with the module number is displayed. Click the
Next button.
14. On the printer Control Panel, the Erasing Flash... --> Diagnosing
message is displayed. The the printer starts updating the firmware.
Caution
Do Not reboot or turn off the printer. The printer will automatically reboot.
12. When the process is completed, the following messages are displayed on
the printer Control Panel.
■ Xerox (TM) Print Cartridge
■ Processing... Ready
13. Print the printer Configuration page (Menu > Information Pgs >
Configuration) and verify the Boot Version information.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
