Xerox Phaser 6125 Service Manual

4-50 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
AC Supply Problems
5 Reseat the Imaging Unit.
Does the electrical noise error still occur?
Go to step 6. Complete
6 Reseat the Transfer Unit.
Does the electrical noise error still occur?
Reseat the
HVPS.
Complete
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ LVPS, PL8.2.1
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 NOTE: During this test, close the Front
Cover.
Does the motor noise occur when the
power is turned on?
Go to FIP-DC. Go to step 2.
2 1.Connect the printer power cord to
another electrical outlet.
2.Turn the printer power On.
Does the printer operate normally?
Complete Go to step 3.
3 1.Turn the printer power Off.
2.Reconnect the printer power cord.
3.Turn the printer power On.
Does the printer operate normally?
Complete Go to step 4.
4 Test the GFI Breaker
Does the GFI Breaker operate normally?
Complete Go to step 5.
5 1.Turn the printer power Off.
2.Disconnect the power cord and wait for
one minute.
3.Reseat the LVPS connectors.
4.Turn the printer power On.
Does the printer operate normally?
Complete Go to step 6.
6 1.Turn the printer power Off.
2.Disconnect the printer power cord and
wait for one minute.
3.Reconnect the power cord.
4.Turn the printer power On.
Does the printer operate normally?
Complete Replace the
LVPS Board.
(Refer to
Removal 13/
Replacement
40.)
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
