Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 23
General Information
Toner Remaining Amount
The CentreWare Internet Services (IS) and PrintingScout (SimpleMonitor)
allow the printer to display toner remaining amount.
Maintenance Function
Firmware Update
The Image Processor Board and Multi-Protocol Network Card firmware can
be updated by customers and service technicians using a Windows PC or
Macintosh with dedicated utilities. Firmware updates are available at
www.xerox.com/office/support.
Detailed procedures are available in “Firmware Update” on page A-3.
Note
Boot Code can be updated via USB port only.
Toner Cartridge Control Panel Display
Toner
Cartridge Control Panel Display Functionality
Normal Status
Life
Warning
Error
End of
Life Error
Xerox Xerox (TM)
Toner Cartridge
Replace
Soon
Replace
Toner
Cartridge
Prints with full
functionality.
Xerox (refill
Toner
Cartridge)
Xerox (TM)
Toner Cartridge
Replace
Soon
Empty Prints with full
functionality up to 40%
of the Toner Cartridge
life.
Other OEM
(non-Xerox
printer
manufacturer)
Non-Xerox
Toner Cartridge
Printer displays error
and will not print.
Non-Xerox
Toner Cartridge
Manufacturer
Non-Xerox
Toner Cartridge
No Life
Tracking
Replace
Toner
Cartridge
Prints with full
functionality.
Updated Firmware Windows
Via USB/IEEE1284 Via Network (port 9100)
Image Processor Board Available Available
Multi Protocol Network Card Available Available
MCU Board
a
a. MCU Board cannot be updated when ROM starts to be used for MCU Board.
Available Available

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
