Xerox Phaser 6125 Service Manual

4-46 Phaser 6125/6130 Color Laser Printer Service Manual
General Troubleshooting
Abnormal Noise During Printing
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Separator Roller Assembly (PL2.1.5)
■ Feed Roller Assembly (PL3.2.4)
■ Imaging Unit (PL4.1.21)
■ Fuser (PL6.1.1)
■ Transfer Unit (PL6.1.7)
■ Sub Drive Assembly (PL7.1.1)
■ Main Drive Assembly (PL7.1.2)
■ Fan (PL8.1.1)
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Is the noise present when paper is fed from
the Tray?
Go to step 2. Go to step 6.
2 Check the paper condition in the Tray
Is the paper dry and approved paper?
Go to step 4. Replace with
dry and
approved
paper, then
go to step 3.
3 Check noise when the paper is fed from the
Tray 1
Is the noise still present?
Go to step 4. Complete
4 1. Remove the Paper Tray from the printer.
2.Rotate the Separator Roller in the Paper
Tray with your finger.
Does the Separator Roller rotate smoothly?
Go to step 5. Replace the
Separator
Roller
Assembly
(page 8-7).
5 Check the Feed Roller Assembly for rotation
1.Remove the Paper Tray from the printer.
2.Start the Main Motor FULL2 test
(page 4-27): Service Mode > Engine
Diag > Motor Test > Main Motor FULL2,
then while the motor is running, start the
Tray Feed Solenoid (Auto) test
(page 4-34): Service Mode > Engine
Diag > Motor Test > Tray Feed Solenoid
(Auto).
Is the noise coming from this Roller?
NOTE: After check is completed, turn off the
Tray Feed Solenoid test first, then turn off
the Main Motor FULL2 test.
Replace the
Feed Roller
Assembly
(page 8-30).
Go to step 9.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
