Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 4-47
General Troubleshooting
6 Check the setting of the Manual Feed Slot
paper guides
Were the paper guides correctly set, and
was the paper correctly inserted into
Manual Feed?
Go to step 7. Reset the
paper guides,
and insert the
paper
correctly in
the Manual
Feed Slot,
then go to
step 7.
7 Check the paper condition
Is the paper dry and approved paper?
Go to step 9. Replace with
dry and
approved
paper, then
go to step 8.
8 Check noise when the paper is fed from the
Manual Feed
Does the noise come from the printer?
Go to step 9 Complete
9 Perform the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor Test
> Main Motor FULL2.
Does the noise arise from the printer?
Go to step 10. Go to step 16.
10 1.Reseat the Imaging Unit.
2.Perform the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Go to step 11. Complete
11 1.Reseat the connectors on the Transfer
Unit.
2.Perform the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2.
Is the noise still present?
Go to step 12. Complete
12 Are there any foreign substances on the
surfaces of the Registration Roller
Assembly and Metal Registration Roller?
Remove the
foreign
substances,
then go to
step 13.
Go to step 14.
13 Check noise when printing
Is the noise still present?
Go to step 14. Complete
14 Check the Registration and Metal
Registration Rollers for rotation
1.Start the Main Motor test (page 4-27):
Service Mode > Engine Diag > Motor
Test > Main Motor FULL2, and while the
motor is running start the Regi Clutch
test: Service Mode > Engine Diag >
Motor Test > Regi Clutch.
Is the noise coming from the Roller(s)?
Replace the
Registration
Roller
Assembly
and/or Metal
Registration
Roller.
Go to step 15.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
