Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 4-41
General Troubleshooting
DC Power Supply Troubleshooting
LVPS Overcurrent Protection Circuit
This circuit stops all outputs if any of the Low Voltage Power Supply voltages
3.3 VDC, 5 VDC, or 24 VDC are shorted.
The circuit is reset when the short is removed, the power is turned Off, and
then On again.
LVPS Overvoltage Protection Circuit
This circuit stops all outputs if the power supply voltage 3.3 VDC, 5 VDC, or
24 VDC exceeds the specified voltage respectively. The operating point is 32
VDC or less for 24 VDC, 7 VDC or less for 5 VDC, or 4.4 VDC for 3.3 VDC.
The circuit is reset when the power is turned Off, and then On again after
certain time.
LVPS
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ LVPS, PL8.2.1
■ MCU Board, PL8.2.13
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “DC Power Supply” on page 10-17
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Perform the AC power supply
troubleshooting procedure.
Does the problem persist?
Go to step 2. Complete.
2 Turn the AC power switch Off.
Is the Fuse on the low-voltage power supply
board open?
Replace the
LVPS
(page 8-55).
Go to step 3.
3 1. Disconnect the connectors J501 and
J502 from the LVPS.
2. Turn the AC power Switch On.
3.Measure the DC voltages between the
following pins on the LVPS:
■ P501-1 <=> P501-2 = +5 V
■ P501-3 <=> P501-4 = +3.3 V
■ P502-1 <=> P502-2 = +24 V
Are all of the voltages present?
Go to step 4. Replace the
LVPS
(page 8-55).

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
