Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 10-17
Plug/Jack and Wiring Diagrams
DC Power Supply
MCU
PL8.2.13
Power
Control
Fan
Control
1
3
P/J44
I/L +24VDC
1
2
P/J502
1
2
3
P/J503
LINE
NUT
FAN
PL8.1.1
FAN +24VDC
FAN ALARM
SG
I/L +24VDC
P/J501 P/J14
+3.3VDC
+5VDC
1
2
3
4
7
8
9
10
11
12
13
P/J15
1
2
SG
14
13
12
11
7
8
6
5
4
3
2
4
2
1
2
3
Interlock Harness
PL8.2.5
SG
+5VDC
R/H COVER OPEN
SG
+3.3VDC
SG
1
2
2
1
P/J29P/J291
Switch
PL5.1.9
LV TYPE
DEEP SLEEP
SLEEP
24V ON
FAN ON
FAN LOW
FAN ALARM
14
1
I/L OPEN
Power Switch Harness
PL8.2.9
P/J482
P/J484
P/J48
T484
s6130-059
LVPS
PL8.2.1
GFI Breaker
PL8.2.11
GFI Ground Harness
PL8.2.10
LVPS Harness
PL9.1.3
Side Switch Harness
PL5.1.27
24V Harness
PL9.1.4
Interlock
+24VDC
3
1
P/J483

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
