Xerox Phaser 6125 Service Manual

10-18 Phaser 6125/6130 Color Laser Printer Service Manual
Plug/Jack and Wiring Diagrams
LVPS Over-Current Protection Circuit
This circuit stops all outputs if 3.3 VDC, 5 VDC, or 24 VDC is shorted.
LVPS Over-Voltage Protection Circuit
This circuit stops all outputs, if 3.3 VDC, 5 VDC, or 24 VDC exceeds the
specified voltage respectively.
At this time, the operating point is 36 VDC or less for 24 VDC, 7 VDC or less
for 5 VDC and 3.3 VDC.
Deep Sleep Mode (Power Saver)
The output of the following power supply are stopped according to the signals.
Signal Line Name Description
LV TYPE Controls signal of the LVPS.
DEEP SLEEP
SLEEP
24 V ON
FAN ON Drives control signal of the Main Fan.
FAN LOW
FAN ALARM
Signal
+3.3 VDC +5 VDC +24 VDC
Sleep On Off Off
Deep Sleep Off Off Off

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
