Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 4-43
General Troubleshooting
+24 VDC Interlock Switch
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Interlock Harness, PL8.2.5
■ LVPS, PL8.2.1
■ Top LV Harness, PL10.1.16
■ “Map 4 - Toner Dispenser Motors, HVPS,
MCU” on page 10-11
■ “DC Power Supply” on page 10-17
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the Interlock Harness for continuity.
1.Disconnect P/J44.
2.Check continuity between P/J44-1 <=> P/
J44-3.
Is the circuit continuous when the Interlock
is activated?
Complete Replace the
Interlock
Harness
(page 8-54).

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
