Error Messages and Codes
8 Check power to the Sub Drive
Assembly.
1.Disconnect P/J22 from the MCU
Board.
2.Are there +24 V across J22-2/J22-4
<=> ground when the Interlock
Switch is activated?
Replace the Sub
Drive Assembly
(page 8-53).
Replace the
MCU Board
(page 8-59).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
