Xerox Phaser 6125 Service Manual

Phaser 6130 Color Laser Printer Service Manual A-7
Reference
EEPROM Electrically Erasable Programmable Read-Only Memory
ESA Electric Static Attachment
ESD Electrostatic Discharge. A transfer of charge between
bodies at different electrostactic potential.
ESS Printer Controller
FCC Federal Communications Commission
FDR Feeder
FPOT First Print Output Time
FR/FRNT Front
FRU Field Replaceable Unit
GB Giga Byte
GDI Graphics Device Interface
GND Ground
HARN Harness
HCF High-Capacity Feeder
HDD Hard Disk Drive
HGEA High-Grade Emulsion Aggregation (Toner)
HUM Humidity
HVPS High-Voltage Power Supply
Hz Hertz (cycles per second)
IBT Intermediate Belt Transfer
IC Integrated Circuit
IDT Intermediate Drum Transfer
IEC International Electrotechnical Commission
I/F Interface
IOT Image Output Terminal - the ROS/Xerox/paper handling/
fusing portion of the printer
IP Image Processor
IPX Internetwork Packet Exchange
IQ Image Quality
KB Kilo Byte
LAN Local Area Network
LCD Liquid Crystal Display
LD Laser Diode
LED Light Emitting Diode
LEF Long-Edge Feed
LH Left Hand
Acronym Description

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
