Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 3-47
Error Messages and Codes
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the paper condition
Is the paper wrinkled or damaged?
Replace the
paper. Go to
step 2.
Go to step 3.
2 Does the error still occur when
printing?
Go to step 3. Complete
3 Check the Front Cover for latching
Open and close the Front Cover, and
then latch correctly.
Does the error still occur when
printing?
Go to step 4. Complete
4 Check around the Regi Sensor
Is there any remaining paper and/or
foreign substance around the Regi
Sensor?
Remove the
paper and/or
substance, then
go to step 5.
Go to step 6.
5 Does the error still occur when
printing?
Go to step 6. Complete
6 Check the Transfer Unit
Is there any remaining paper and/or
damage on the belt of the Transfer
Unit?
Remove the
remaining paper.
If the belt is
damaged,
replace the
Transfer Unit
(page 8-41).
Go to step 7.
7 1.Remove the Imaging Unit.
2.Rotate the Registration and Metal
Registration Rollers with your
finger.
Are the Registration and Metal
Registration Rollers seated correctly?
Are they undamaged and free of
contamination, and do they rotate
smoothly?
Go to step 8. Clean the rollers
if possible, or
replace the
Feeder
Assembly
(page 8-25).
8 Check the Regi In and Regi Roll
Actuators for shape and operation.
Are the shape and operation of the
Regi In and Regi Roll Actuators
normal?
Go to step 9. Reseat the Regi
In Actuator and/
or Regi Roll
Actuator.
If broken or
deformed,
replace the
Feeder
Assembly
(page 8-25).

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
