Xerox Phaser 6125 Service Manual

3-68 Phaser 6125/6130 Color Laser Printer Service Manual
Error Messages and Codes
3 1.Close the Front Cover.
2.Perform the Main Motor test
(page 4-27): Service Mode >
Engine Diag > Motor Test > Main
Motor FULL2.
Does the Motor operate properly?
Replace the
MCU Board
(page 8-59).
Go to step 4.
4 Check the wiring harness connectors
P/J21 and P/J211 between the MCU
Board and the Main Drive.
Are the connectors securely
connected?
Go to step 6. Reconnect the
connectors. Go
to step 5.
5 Turn the power Off, then On.
Does the error still occur?
Go to step 6. Complete.
6 Check the Main Drive for correct
installation. Is the Main Drive securely
installed?
Go to step 8. Reseat the Main
Drive. Go to
step 7.
7 Does the error still occur? Go to step 8. Complete.
8 Check the Main Drive signal.
1.Disconnect P/J21 on the MCU
Board.
2.Are there +24 V across ground <=>
J21-2/J21-4 when the Interlock
Switch is activated?
Replace the
Main Drive
Assembly
(page 8-52).
Replace the
MCU Board
(page 8-59).
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
