Phaser 6125/6130 Color Laser Printer Service Manual 5-53
Print-Quality Troubleshooting
19 NOTE: During this check, defeat the
Front Cover interlock switch (HARN
ASSY INTERLOCK).
1.Start the Main Motor FULL2 test:
Service Mode > Engine Diag >
Motor Test > Main Motor FULL2.
2.While it is running, start the Regi
Clutch test: Service Mode > Engine
Diag > Motor Test > Regi Clutch.
Do the Regi Roller Assy and Metal
Regi Roller rotate?
Complete Replace the
Feeder
Assembly
page 8-25.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No
To Next Page
