5-60 Phaser 6125/6130 Color Laser Printer Service Manual
Print-Quality Troubleshooting
4 Does the mis-registration (color shift)
appear on the printed material when
printing?
Go to step 5. Complete
5 Open and close the Front Cover.
Does the Front Cover latch closed
properly?
Complete Replace any
defective parts,
then go to step
6.
6 Open and close the Front Cover.
Does the mis-registration (color shift)
appear on the printed material when
printing?
Go to step 7. Complete
7 Reseat the Imaging Unit.
Does the mis-registration (color shift)
appear on the printed material when
printing?
Go to step 8. Go to step 8.
8 Open and close the Front Cover to
reseat the Transfer Unit.
Does the mis-registration (color shift)
appear on the printed material when
printing?
Go to step 8. Complete
9 Set the printer to adjust the color
registration automatically: Menus >
Admin Menu > Maintenance Mode >
Automatic Registration Adjust.
Does the mis-registration (color shift)
appear on the printed material when
printing?
Go to step 9. Complete
9 Adjust the color registration manually:
Menus > Admin Menu > Maintenance
Mode > Adjust Color Registration.
(Refer to the User Guide.)
Does the mis-registration (color shift)
appear on the printed material when
printing?
Go to step 10. Complete
10 Replace the Imaging Unit (page 8-8).
Is the image printed correctly?
Go to step 11. Complete
11 Replace the Transfer Unit (page 8-41).
Does the mis-registration (color shift)
appear on the printed material when
printing?
Go to step 12. Complete
12 Replace the MCU Board (page 8-59).
Does the mis-registration (color shift)
appear on the printed material when
printing?
Replace the
printer.
Complete
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
