Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 9-13
Parts List
Parts List 4.1 Xerographics
ID No. Name/Description Part Number
1
ROS ASSY (Laser Unit)
a
—
2 SPRING ROS —
3 HOLDER CRUM —
4 SPRING PHD —
5 LEVER PHD —
6 BLOCK STOPPER PHD D —
7 BLOCK STOPPER PHD AD —
8 LED ASSY ERASE 122K94040
9 SPRING TRACKING —
10 SPRING CF —
11 SPRING TR4 —
12 SPRING TR3 —
13 SPRING TR2 —
14 SPRING TR1 —
15 SPRING D4 —
16 SPRING D3 —
17 SPRING D2 —
18 SPRING D1 —
19 PWBA HVPS 105K22661
20 FRAME HVPS 801E01503
21 PHD ASSY (Imaging Unit) 675K69240
22 HARN ASSY ROS RE (J40-J411) —
23 HARN ASSY ROS VIDEO (J41-J412) —
97 KIT BLOCK PHD RIGHT (with 4,5,7 × 2pcs) 675K54241
98 KIT BLOCK PHD LEFT (with 4,5,6 × 2pcs) 675K54251
99 KIT ROS (with 1,2 × 2pcs) (Laser Unit kit) 604K43050
a. Use PL4.1.99, Laser Unit kit, when ordering the Laser Unit.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
