Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 9-15
Parts List
Parts List 5.1 Dispenser
ID No. Name/Description Part Number
1 DISPENSER ASSY (with 2,9-11,14-16,25-27) 094K92290
2 FRAME ASSY MOT (with 3-8) —
3 MOTOR ASSY DISP —
4 CONDUCTOR MOTOR —
5 FRAME MOTOR —
6 GEAR IDLER —
7 GEAR IDLER AUG —
8 GEAR IDLER AGI —
9 SWITCH (R Side Door) 110E10200
10 HOUSING ASSY AUGER —
11 FRAME ASSY DISP (with 12,13) —
12 FRAME DISP —
13 SEAL DISP AUG —
14 CONNECTOR CRUM —
15 SPRING DISP —
16 JOINT ASSY DISP —
17 HOLDER TCRU K 604K44920
18 HOLDER TCRU C 604K44930
19 HOLDER TCRU M 604K44940
20 HOLDER TCRU Y 604K44950
21B TONER CARTRIDGE US/EU 2.5K (K) 675K59231
21C TONER CARTRIDGE DMO 2.5K (K) 675K59311
21D TONER CARTRIDGE US/EU (GDI) 6125 (K) 106R01334
21E TONER CARTRIDGE DMO (GDI) 6125 (K) 106R01338
22B TONER CARTRIDGE US/EU 2K (C) 675K59241
22C TONER CARTRIDGE DMO 2K (C) 675K59321
22D TONER CARTRIDGE US/EU (GDI) 6125 (C) 106R01331
22E TONER CARTRIDGE DMO (GDI) 6125(C) 106R01335
23B TONER CARTRIDGE US/EU 2K (M) 675K59251
23C TONER CARTRIDGE DMO 2K (M) 675K59331
23D TONER CARTRIDGE US/EU (GDI) 6125 (M) 106R01332
23E TONER CARTRIDGE DMO (GDI) 6125 (M) 106R01336
24B TONER CARTRIDGE US/EU 2K (Y) 675K59261
24C TONER CARTRIDGE DMO 2K (Y) 675K59341
24D TONER CARTRIDGE US/EU (GDI) 6125 (Y) 106R01333
24E TONER CARTRIDGE DMO (GDI) 6125 (Y) 106R01337
25 HARN ASSY TNR MOT (J18,J19-J181,J182,J191,J192) —
26 HARN ASSY TONER CRUM (J31-J311,J312,J313,J314) —
27 HARN ASSY SIDE SW (J29-J291) —
28 HARN ASSY TEST RL (J504-P5041) —

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
