Xerox Phaser 6125

Phaser 6125/6130 Color Laser Printer Service Manual 9-21
Parts List
Parts List 8.1 Electrical (1/2)
ID No. Name/Description Part Number
1 FAN 127E85360
2 DUCT FAN —
3 Shield Assy ESS (Image Processor Shield) —
4 PLATE ESS —
5 Screw Knurling —
6 Washer —
7 Frame ESS (Image Processor Frame) —
8 Plate IF —
9A
9B
PWBA ESS Phaser 6130 (with 10) (I/P Board)
PWBA ESS Phaser 6125 (with 10) (I/P Board)
960K36163
960K38520
10 NVM ROM REF ONLY
11 MULTI PROTOCOL CARD (OPTION) 097S03745
