Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 9-23
Parts List
Parts List 8.2 Electrical (2/2)
ID No. Name/Description Part Number
1A
1B
PWBA LVPS 100V
PWBA LVPS 200V
105K22382
105K22721
2 Guide Harness Fsr —
3 Frame Assy LVPS —
4 Plate Earth —
5 Harn Assy Interlock (SW-J44) (Front Cover) 962K52120
6 Guide Harness AC —
7 Sensor Hum (Humidity Sensor) 130E93460
8 Bracket SW —
9 A
9 B
HARN ASSY SW PWR (SW-J48,J482,J483) 100V
HARN ASSY SW PWR (SW-J48,J482,J483) 200V
962K62110
962K62120
10 HARN ASSY GFI GND (J484-T484) —
11 BREAKER GFI 908W01201
12 A
12 B
Power Cord 110V
Power Cord 220V
675K17830
675K17660
13 PWBA MCU 960K36420
14 EDGING SADDLE —
15 BRACKET MCU R —
16 PWBA EEPROM (XPRO) 960K32640
17 CLAMP —
18 BRACKET MCU L —
19 GUIDE HARNESS MCU —

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
