Xerox Phaser 6125

Phaser 6125/6130 Color Laser Printer Service Manual 9-25
Parts List
Parts List 9.1 Wiring Harness
ID No. Name/Description Part Number
1 Harn Assy ESS (Image Processor) (J10-J101) —
2 Harn Assy ESS (Image Processor) Video (J11-J111) —
3 Harn Assy LVPS (J14-J141,J501) —
4 Harn Assy 24V (J15-J502) —
5 Harn Assy HVPS (J16-J161) —
6 Harn Assy HUM (J20-J201) —
7 Harn Assy Main Mot (J21-J211) —
8 Harn Assy Sub Mot (J22-J221) —
9 Harn Assy KSNR REGCL (J26-J261,P262) —
10 Harn Assy ESS (Image Processor) Power (J40-J401) —
11 Harn Assy PHD XPRO (J42-J144,P422) —
12 Harness Assy B (J29-J2900) —
