Xerox Phaser 6125 Service Manual

Phaser 6125/6130 Color Laser Printer Service Manual 10-25
Plug/Jack and Wiring Diagrams
Signal Line Name Description
CLOCK Control signals of the EEPROM Board.
DATA
CLOCK Control signals of the Imaging Unit EEPROM Board.
DATA
TEMP. Temperature data in the printer by the Humidity/
Temperature Sensor (Analog value).
HUMI. Provides Humidity/Temperature data in the printer by
the Humidity/Temperature Sensor (Analog value).
ERASE K ON (L) +3.3 VDC On/Off signals of the Erase LEDs.
ERASE Y/M/C ON (L) +3.3
VDC
ADC SENSOR Toner patch density data measured by the ADC Sensor
(Analog value).
LED REM Remote signal of the LED of the ADC Sensor.
ADC V MONI Control signal of the ADC Sensor.

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
