Phaser 6130 Color Laser Printer Service Manual A-9
Reference
PWB Printed Wiring Board
PWBA Printed Wiring Board Assembly
RAM Random Access Memory
RegiCon Registration Control
RET Retard
RH Relative Humidity
RLS Release
RMS Root Mean Square Voltage
ROM Read-Only Memory
ROS Raster Output Scanner - Laser Unit
RTD Retard
SEF Short-Edge Feed
SLP Service Location Protocol
SMB Server Message Block
SNMP Simple Network Management Protocol
SNR Sensor
SOL Solenoid
SOS Start of Scan
STS Soft Touch Sensor
TDC Toner Density Control
TNR Toner
TRNS Transport
UI User Interface
USB Universal Serial Bus
WINS Wireless Integrated Network Sensor
Acronym Description

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
