Xerox Phaser 6125 Service Manual

2-44 Phaser 6125/6130 Color Laser Printer Service Manual
Theory of Operation
Development and Excess Toner Collection
Main Drive Sub Drive
Print Cartridge Gear 1
Xerographics Housing (Y, M, C, K)
[ Drum ]
Print Cartridge Gear 2
Cleaning Auger Gear
Magnet Idler Gear
Paddle Idler Gear
Paddle Gear
Auger Gear
Auger Gear
Side Auger Idler Gear
Side Auger Gear
[ Side Cleaning Auger ] [ Developer Paddle ]
[ Auger Front ]
[ Auger Rear ]
[ Auger ]
Developer Housing (Y, M, C, K)
[ Magnet Roller ]
Magnet Gear (Y, M, C, K)
[ Name Of Moving Parts ]
Development And Excess Toner Collecting
Imaging Unit
s6130-030

Xerox Phaser 6125 Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	17 s
Time to first page (color, normal)	14 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Internal memory	64 MB
Sound power level (standby)	25.7 dB
Sound pressure level (printing)	51.6 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Media weight (tray 1)	64 - 220 gsm
Paper tray media types	Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Letter
Multi-Purpose Tray media weight	64 - 164 g/m²
Power requirements	240 V, 50/60 Hz
Networking features	10/100BaseTX
Power consumption (active)	280 W
Maximum duty cycle	40000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	50 W
Power consumption (PowerSave)	5 W
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 89/336/EEC, FCC 15 B, 73/23/EEC, 2002/95/EC

Weight and Dimensions

Dimensions (WxDxH)	400 x 394 x 389 mm
