52 www.xilinx.com 7 Series FPGAs SelectIO Resources User Guide

UG471 (v1.10) May 8, 2018

Chapter 1: SelectIO Resources

Figure 1-37 shows unidirectional terminated topologies.

X-Ref Target - Figure 1-3 7

Figure 1-37: LVTTL Unidirectional Termination

IOB

LVTTL

IOB

LVTTL

IOB

LVTTL

ug471_c1_27_011811

Note: V

is any voltage from 0V to V

CCO

= Z

– R

Send Feedback
