Supported I/O Standards and Terminations
Figure 1-54 shows a sample circuit illustrating a termination technique for differential
HSTL class-II (1.5V or 1.8V) with bidirectional DCI termination. In a specific circuit, all
drivers and receivers must be at the same voltage level (either 1.5V or 1.8V); they are not
interchangeable. Only HP I/O banks support the DCI standards. The internal
split-termination resistors are always present, independent of whether the drivers are
3-stated.
