YASKAWA A1000 Series

Step Display/Result
10.
Press
to confirm the change.
Entry Accepted
11. The display automatically returns to the screen shown in Step 4.
-PRMSET-
C1-02= 20.0Sec
(0.0~6000.0)
“10.0 sec”
PRG
Decel Time 1
← →
FWD
12.
Press as many times as necessary to return to the initial display.
- MODE -
U1-01= 0.00Hz
U1-02= 0.00Hz
U1-03= 0.00A
DRV
FREF (OPR)
Rdy
JOG FWD FWD/REV
LSEQ
LREF
n
Setup Group Parameters
Table 4.4
lists the parameters available by default in the Setup Group. Selecting an Application Preset in parameter A1-06 or
from the Application Selection Menu of the Setup Group automatically changes the parameters selected for the Setup Group.
Refer to Application Selection on page 134 for more information.
Use the Programming Mode to access parameters not displayed in the Setup Group.
Table 4.4 Setup Group Parameters
Parameter Name
A1-02 Control Method Selection
b1-01 Frequency Reference Selection 1
b1-02 Run Command Selection 1
b1-03 Stopping Method Selection
C1-01 Acceleration Time 1
C1-02 Deceleration Time 1
C6-01 Drive Duty Mode
C6-02 Carrier Frequency Selection
d1-01 Frequency Reference 1
d1-02 Frequency Reference 2
d1-03 Frequency Reference 3
d1-04 Frequency Reference 4
d1-17 Jog Frequency Reference
Parameter Name
E1-01 Input Voltage Setting
E1-03 V/f Pattern Selection
E1-04 Maximum Output Frequency
E1-05 Maximum Voltage
E1-06 Base Frequency
E1-09 Minimum Output Frequency
E1-13 Base Voltage
E2-01 Motor Rated Current
E2-04 Number of Motor Poles
E2-11 Motor Rated Power
H4-02 Multi-Function Analog Output Terminal FM Gain
L1-01 Motor Overload Protection Function Selection
L3-04 Stall Prevention Selection during Deceleration
Note: 1. Parameter availability depends on the control mode set in A1-02; some parameters listed above may not be accessible in all control
modes.
2. Parameters listed in Table 4.4 are set in alphanumeric order as User Parameters in A2-01 to A2-26.
4.2 The Drive and Programming Modes
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
125
4
Start-Up Programming & Operation
