YASKAWA A1000 Series User Manual

CIMR - A U 2 A
0021 F
A A
Drive
A1000
Series
No.
Enclosure
Type <2>
Design
Revision
Order
No.
Customized
Specifications
A Standard model
IP00/Open
Type
F
IP20/NEMA 1,
UL Type 1
A
No.
Environmental
Specification <4>
K Gas-resistant
A
M
N
S
Standard
Humidity- and
dust-resistant
Oil-resistant
Vibration-resistant
Refer to the tables below
No.
Region
Code
Japan
China
Europe
India
Asia
USA
A
B
C
D
T
U
No. Voltage Class
3-phase, 380-480 Vac
3-phase, 200-240 Vac
2
4
3-phase, 500-600 Vac 5
U
Flange
Type <3>
T
6-Phase/
12-Pulse Input <1>
<1> Refer to manual TOEP C710616 50 for information on 12-pulse models.
<2> Refer to Mechanical Installation on page 28 for differences regarding enclosure protection types and component
descriptions.
<3> Provides method of mounting drive with backside (heatsink) external to enclosure, with NEMA 12, UL Type 12 integrity.
<4> Drives with these specifications do not guarantee complete protection for the environmental conditions indicated.
n
Three-Phase 200 V
Table 1.1 Model Number and Specifications (200 V)
Normal Duty (ND)
C6-01 = 1
Heavy Duty (HD)
C6-01 = 0
Drive Model
Max. Motor Capacity
kW (HP)
Rated Output
Current A
Drive Model
Max. Motor Capacity
kW (HP)
Rated Output
Current A
2A0004 0.75 (0.75) 3.5 2A0004 0.4 (0.75) 3.2
2A0006 1.1 (1) 6.0 2A0006 0.75 (1) 5
2A0008 1.5 (2) 8.0 2A0008 1.1 (2) 6.9
2A0010 2.2 (3) 9.6 2A0010 1.5 (2) 8
2A0012 3.0 (3) 12 2A0012 2.2 (3) 11
2A0018 3.7 (5) 17.5 2A0018 3.0 (3) 14.0
2A0021 5.5 (7.5) 21 2A0021 3.7 (5) 17.5
2A0030 7.5 (10) 30 2A0030 5.5 (7.5) 25
2A0040 11 (15) 40 2A0040 7.5 (10) 33
2A0056 15 (20) 56 2A0056 11 (15) 47
2A0069 18.5 (25) 69 2A0069 15 (20) 60
2A0081 22 (30) 81 2A0081 18.5 (25) 75
2A0110 30 (40) 110 2A0110 22 (30) 85
2A0138 37 (50) 138 2A0138 30 (40) 115
2A0169 45 (60) 169 2A0169 37 (50) 145
2A0211 55 (75) 211 2A0211 45 (60) 180
2A0250 75 (100) 250 2A0250 55 (75) 215
2A0312 90 (125) 312 2A0312 75 (100) 283
2A0360 110 (150) 360 2A0360 90 (125) 346
2A0415 110 (175) 415 2A0415 110 (150) 415
1.1 Model Number and Nameplate Check
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
23
1
Receiving

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
