YASKAWA A1000 Series User Manual

Normal Duty (ND)
C6-01 = 1
Heavy Duty (HD)
C6-01 = 0
Drive Model
Max. Motor Capacity
kW (HP)
Rated Output
Current A
Drive Model
Max. Motor Capacity
kW (HP)
Rated Output
Current A
5A0077 55 (75) 77 5A0077 45 (50-60) 62
5A0099 75 (100) 99 5A0099 55 (75) 77
5A0125 90 (125) 125 5A0125 75 (100) 99
5A0145 110 (150) 145 5A0145 90 (125) 130
5A0192 160 (200) 192 5A0192 110 (150) 172
5A0242 185 (250) 242 5A0242 160 (200) 200
1.1 Model Number and Nameplate Check
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
25
1
Receiving

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
