YASKAWA A1000 Series User Manual

Drive Model
Heavy Duty
Nominal
Output Power
HP
AC Drive Input
Amps
MCCB Rating
Amps
<1>
Time Delay Fuse
Rating Amps
<2>
Non-time Delay
Fuse Rating
Amps
<3>
Bussmann Semi-
conductor Fuse
Rating (Fuse
Ampere)
<4>
4A0004 1 - 2 3.2 15 5 9 FWH-50B (50)
4A0005 3 4.4 15 7 12 FWH-70B (70)
4A0007 3 6 15 10 17.5 FWH-70B (70)
4A0009 5 8.2 15 12 20 FWH-90B (90)
4A0011 5 10.4 20 17.5 30 FWH-90B (90)
4A0018 7.5 - 10 15 30 25 40 FWH-80B (80)
4A0023 10 20 40 35 60 FWH-100B (100)
4A0031 15 29 50 50 80 FWH-125B (125)
4A0038 20 39 75 60 110 FWH-200B (200)
4A0044 25 - 30 47 75 75 125 FWH-250A (250)
4A0058 30 43 75 75 125 FWH-250A (250)
4A0072 40 58 100 100 150 FWH-250A (250)
4A0088 60 71 125 110 200 FWH-250A (250)
4A0103 60 86 150 150 250 FWH-250A (250)
4A0139 75 105 175 175 300 FWH-350A (350)
4A0165 100 142 225 225 400 FWH-400A (400)
4A0208 125 - 150 170 250 250 500 FWH-500A (500)
4A0250 150 207 350 350 600 FWH-600A (600)
4A0296 200 248 400 400 700 FWH-700A (700)
4A0362 250 300 500 500 800 FWH-800A (800)
4A0414 300 346 600 600
1000
<4>
FWH-800A (800)
4A0515 350 410 700 700
1200
<4>
FWH-1000A (1000)
4A0675 400 - 500 584 1000
1000
<4>
1600
<4>
FWH-1200A (1200)
4A0930 600 - 700 830
Not Applicable
FWH-1200A (1200)
4A1200 800 - 900 1031 FWH-1600A (1600)
600 V Class
5A0003 1 1.9 15 3 5 FWP-50B (50)
5A0004 2 3.6 15 6.25 10 FWP-50B (50)
5A0006 3 5.1 15 8 15 FWP-60B (60)
5A0009 5 8.3 15 12 20 FWP-60B (60)
5A0011 7.5 12 20 20 35 FWP-70B (70)
5A0017 10 16 30 25 45 FWP-100B (100)
5A0022 15 23 40 40 60 FWP-100B (100)
5A0027 20 31 60 50 90 FWP-125A (125)
5A0032 25 38 75 60 100 FWP-125A (125)
5A0041 30 33 60 50 90 FWP-175A (175)
5A0052 40 44 75 75 125 FWP-175A (175)
5A0062 50 54 100 90 150 FWP-250A (250)
5A0077 60 66 125 110 175 FWP-250A (250)
5A0099 75 80 150 125 225 FWP-250A (250)
5A0125 100 108 175 175 300 FWP-350A (350)
5A0145 125 129 250 225 350 FWP-350A (350)
5A0192 150 158 300 250 400 FWP-600A (600)
5A0242 200 228 400 350 600 FWP-600A (600)
<1> Maximum MCCB Rating is 15 A, or 200 % of drive input current rating, whichever is larger. MCCB voltage rating must be 600 VAC or greater.
<2>
Maximum Time Delay fuse is 175% of drive input current rating. This covers any Class CC, J or T class fuse.
<3> Maximum Non-time Delay fuse is 300% of drive input current rating. This covers any CC, J or T class fuse.
C.2 UL and CSA Standards
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
347
C
Standards Compliance

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
