YASKAWA A1000 Series User Manual

Drive Model
Normal Duty
Nominal
Output Power
HP
AC Drive Input
Amps
MCCB Rating
Amps
<1>
Time Delay Fuse
Rating Amps
<2>
Non-time Delay
Fuse Rating
Amps
<3>
Bussmann Semi-
conductor Fuse
Rating (Fuse
Ampere)
<4>
5A0022 20 31 60 50 90 FWP-100B (100)
5A0027 25 38 75 60 110 FWP-125A (125)
5A0032 30 45 75 75 125 FWP-125A (125)
5A0041 40 44 75 75 125 FWP-175A (175)
5A0052 50 54 100 90 150 FWP-175A (175)
5A0062 60 66 125 110 175 FWP-250A (250)
5A0077 75 80 150 125 225 FWP-250A (250)
5A0099 100 108 175 175 300 FWP-250A (250)
5A0125 125 129 225 225 350 FWP-350A (350)
5A0145 150 158 300 275 450 FWP-350A (350)
5A0192 200 228 400 350 600 FWP-600A (600)
5A0242 250 263 500 450 700 FWP-600A (600)
<1> Maximum MCCB Rating is 15 A, or 200 % of drive input current rating, whichever is larger. MCCB voltage rating must be 600 VAC or greater.
<2>
Maximum Time Delay fuse is 175% of drive input current rating. This covers any Class CC, J or T class fuse.
<3> Maximum Non-time Delay fuse is 300% of drive input current rating. This covers any CC, J or T class fuse.
<4> When using semiconductor fuses, Bussman FWH and FWP are required for UL compliance. Select FWH for 200 V Class and 400 V Class models
and FWP fuses for 600 V models.
<5> Class L fuse is also approved for this rating.
Table C.8 Factory Recommended Drive Branch Circuit Protection (Heavy Duty)
Drive Model
Heavy Duty
Nominal
Output Power
HP
AC Drive Input
Amps
MCCB Rating
Amps
<1>
Time Delay Fuse
Rating Amps
<2>
Non-time Delay
Fuse Rating
Amps
<3>
Bussmann Semi-
conductor Fuse
Rating (Fuse
Ampere)
<4>
200 V Class
2A0004 0.75 2.9 15 5 8 FWH-70B (70)
2A0006 1 5.8 15 10 15 FWH-70B (70)
2A0008 2 7 15 12 17.5 FWH-70B (70)
2A0010 2 7.5 15 12 20 FWH-70B (70)
2A0012 3 11 20 17.5 30 FWH-70B (70)
2A0018 3 15.6 25 25 40 FWH-90B (90)
2A0021 5 18.9 35 30 50 FWH-90B (90)
2A0030 7.5 28 50 40 75 FWH-100B (100)
2A0040 10 37 60 60 100 FWH-200B (200)
2A0056 15 52 100 90 150 FWH-200B (200)
2A0069 20 68 125 110 200 FWH-200B (200)
2A0081 25 80 150 125 225 FWH-300A (300)
2A0110 30 82 150 125 225 FWH-300A (300)
2A0138 40 111 200 175 250 FWH-350A (350)
2A0169 50 136 250 225 350 FWH-400A (400)
2A0211 60 164 300 250 450 FWH-400A (400)
2A0250 75 200 400 350 600 FWH-600A (600)
2A0312 100 271 500 450 800 FWH-700A (700)
2A0360 125 324 600 500
900
<4>
FWH-800A (800)
2A0415 150 394 700 600
1100
<4>
FWH-1000A (1000)
400 V Class
4A0002 0.75 1.8 15 3 5 FWH-40B (40)
C.2 UL and CSA Standards
346
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
