YASKAWA A1000 Series User Manual

Drive Model
Normal Duty
Nominal
Output Power
HP
AC Drive Input
Amps
MCCB Rating
Amps
<1>
Time Delay Fuse
Rating Amps
<2>
Non-time Delay
Fuse Rating
Amps
<3>
Bussmann Semi-
conductor Fuse
Rating (Fuse
Ampere)
<4>
2A0040 15 52 100 90 150 FWH-200B (200)
2A0056 20 68 125 110 200 FWH-200B (200)
2A0069 25 80 150 125 225 FWH-200B (200)
2A0081 30 96 175 150 275 FWH-300A (300)
2A0110 40 111 200 175 300 FWH-300A (300)
2A0138 50 136 250 225 400 FWH-350A (350)
2A0169 60 164 300 250 450 FWH-400A (400)
2A0211 75 200 400 350 600 FWH-400A (400)
2A0250 100 271 500 450 800 FWH-600A (600)
2A0312 125 324 600 500 800 FWH-700A (700)
2A0360 150 394 700 600
1000
<5>
FWH-800A (800)
2A0415 175 471 900 800
1400
<5>
FWH-1000A (1000)
400 V Class
4A0002 1 2.1 15 3.5 6 FWH-40B (40)
4A0004 2 4.3 15 7.5 12 FWH-50B (50)
4A0005 3 5.9 15 10 17.5 FWH-70B (70)
4A0007 3 8.1 15 12 20 FWH-70B (70)
4A0009 5 9.4 15 15 25 FWH-90B (90)
4A0011 7.5 14 25 20 40 FWH-90B (90)
4A0018 10 20 40 35 60 FWH-80B (80)
4A0023 15 24 45 40 70 FWH-100B (100)
4A0031 20 38 75 60 110 FWH-125B (125)
4A0038 25 44 75 75 125 FWH-200B (200)
4A0044 30 52 100 90 150 FWH-250A (250)
4A0058 40 58 100 100 150 FWH-250A (250)
4A0072 50 71 125 110 200 FWH-250A (250)
4A0088 60 86 150 150 250 FWH-250A (250)
4A0103 75 105 200 175 300 FWH-250A (250)
4A0139 100 142 250 225 400 FWH-350A (350)
4A0165 125 170 300 250 500 FWH-400A (400)
4A0208 150 207 400 350 600 FWH-500A (500)
4A0250 200 248 450 400 700 FWH-600A (600)
4A0296 250 300 600 500 800 FWH-700A (700)
4A0362 300 346 600 600
1000
<5>
FWH-800A (800)
4A0414 350 410 800 700
1200
<5>
FWH-800A (800)
4A0515 400 - 450 465 900 800
1350
<5>
FWH-1000A (1000)
4A0675 500 - 600 657 1200
1100
<5>
1800
<5>
FWH-1200A (1200)
4A0930 700 - 800 922
Not Applicable
FWH-1200A (1200)
4A1200 900 - 1000 1158 FWH-1600A (1600)
600 V Class
5A0003 2 3.6 15 6.25 10 FWP-50B (50)
5A0004 3 5.1 15 8 15 FWP-50B (50)
5A0006 5 8.3 15 12 20 FWP-60B (60)
5A0009 7.5 12 20 20 35 FWP-60B (60)
5A0011 10 16 30 25 45 FWP-70B (70)
5A0017 15 23 40 40 60 FWP-100B (100)
C.2 UL and CSA Standards
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
345
C
Standards Compliance

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
