Table C.13 Safety Input and EDM Terminal Status
Safe Disable Input Status
Safe Disable Status Monitor,
DM+ DM-
Drive Output Status
Digital Operator
Display
Input 1, H1-HC Input 2, H2-HC S6 Switch = “N.C.” S6 Switch = “N.O.”
OFF OFF OFF ON
Safely disabled,
“Safe Torque Off”
Hbb (flashes)
ON OFF ON OFF
Safely disabled,
“Safe Torque Off”
HbbF (flashes)
OFF ON ON OFF
Safely disabled,
“Safe Torque Off”
HbbF (flashes)
ON ON ON OFF
Baseblock,
ready for operation
Normal display
Safe Disable Status Monitor
Slide Switch S6 controls the polarity of this signal. Refer to Table C.13 for functionality.
With the Safe Disable monitor output (terminals DM+ and DM-), the drive provides a safety status feedback signal. This signal
should be read by the device that controls the Safe Disable inputs (PLC or a safety relay) in order to prohibit leaving the “Safe
Torque Off” status in case the safety circuit malfunctions. Refer to the instruction manual of the safety device for details on
this function.
Digital Operator Display
When both Safe Disable inputs are open, “Hbb” will flash in the digital operator display.
If one Safe Disable channel is on while the other is off, “HbbF” will flash in the display to indicate that there is a problem in
the safety circuit or in the drive. This display should not appear under normal conditions if the Safe Disable circuit is utilized
properly. Refer to Alarm Codes, Causes, and Possible Solutions on page 196 to resolve possible errors.
C.3 Safe Disable Input Function
354
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
