Table 2.7 Dimensions for IP00/Open Type Enclosure: 400 V Class
Drive
Model
Figure
Dimensions mm (in)
Wt. kg
(lb)
W H D W1 W2 W3 W4 H1 H2 D1 t1 t2 d
4A0208A
<1>
1
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
– –
680
(26.77)
12.4
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
79
(174.2)
4A0250A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
– –
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
96
(211.6)
4A0296A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
– –
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
102
(224.9)
4A0362A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
– –
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
107
(235.9)
4A0414A 2
500
(19.69)
950
(37.40)
370
(14.57)
370
(14.57)
7.9
(0.31)
– –
923
(36.34)
13
(0.51)
135
(5.31)
4.6
(0.18)
4.6
(0.18)
M12
125
(275.6)
4A0515A
3
670
(26.38)
1140
(44.88)
370
(14.57)
440
(17.32)
6
(0.24)
220
(8.66)
–
1110
(43.70)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
216
(476.2)
4A0675A
670
(26.38)
1140
(44.88)
370
(14.57)
440
(17.32)
6
(0.24)
220
(8.66)
–
1110
(43.70)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
221
(487.2)
4A0930A 4
1250
(49.21)
1380
(54.33)
370
(14.57)
1110
(43.70)
6
(0.24)
330
(13.00)
440
(17.32)
1345
(52.95)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
545
(1201.5)
4A1200A 4
1250
(49.21)
1380
(54.33)
370
(14.57)
1110
(43.70)
6
(0.24)
330
(13.00)
440
(17.32)
1345
(52.95)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
555
(1223.6)
<1> Customers may convert these models to IP20/NEMA 1, UL Type 1 enclosures using an IP20/NEMA 1, UL Type 1 Kit.
Table 2.8
Dimensions for IP00/Open Type Enclosure: 600 V Class
Drive
Model
Figure
Dimensions mm (in)
Wt. kg
(lb)
W H D W1 W2 W3 W4 H1 H2 D1 t1 t2 d
5A0125A
<1>
1
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
– –
680
(26.77)
12.4
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
79
(174.2)
5A0145A
<1>
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
– –
680
(26.77)
12.4
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
79
(174.2)
5A0192A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
– –
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
107
(235.9)
5A0242A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
– –
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
107
(235.9)
<1> Customers may convert these models to IP20/NEMA 1, UL Type 1 enclosures using an IP20/NEMA 1, UL Type 1 Kit.
2.1 Mechanical Installation
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
39
2
Mechanical Installation

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
