YASKAWA A1000 Series User Manual

IP20/NEMA 1, UL Type 1 Kit Selection
Customers may convert IP00/Open Type models to IP20/NEMA 1, UL Type 1 enclosures. Refer to Table 2.9 to select the
appropriate IP20/NEMA 1, UL Type 1 Kit when performing the conversion.
Contact a Yaskawa representative for IP20/NEMA 1, UL Type 1 Kit availability for IP00/Open Type models not listed.
Table 2.9
IP20/NEMA 1, UL Type 1 Kit Selection
IP00/Open Type
Drive Model
IP20/NEMA 1, UL Type 1 Kit Code Comments
2A0250A
100-054-503
Refer to IP20/NEMA
1, UL Type 1 Enclosure
Drives on page 32 for drive dimensions with the
IP20/NEMA 1, UL Type 1 Kit installed.
2A0312A
2A0360A
4A0208A
4A0250A
100-054-5044A0296A
4A0362A
5A0125A
100-054-503
5A0145A
5A0192A
100-054-504
5A0242A
2.1 Mechanical Installation
40
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
