Flange Type Heat Loss Data
Table 2.10
Models 2A0004 to 2A0012, 4A0002 to 4A0005, and 5A0003 and 5A0004
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
2A0004
200
47.3 18.4 65.7 44.4 14.8 59.2 3.3 (7.3)
2A0006 51.4 30.8 82.2 47.6 24.1 71.7 3.3 (7.3)
2A0008 52.1 42.9 95.0 48.9 34.8 83.7 3.4 (7.5)
2A0010 58.4 56.7 115.1 52.1 42.9 95.0 3.4 (7.5)
2A0012 64.4 76.9 141.3 57.9 63.7 121.6 3.4 (7.5)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
4A0002
400
47.9 19.8 67.7 44.7 15.9 60.6 3.4 (7.5)
4A0004 49.2 32.1 81.3 45.7 24.6 70.3 3.4 (7.5)
4A0005 52.8 44.6 97.4 49.4 37.4 86.8 3.4 (7.5)
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 8 kHz)
Internal External Total Internal External Total
5A0003
600
23.3 21.5 44.8 19.8 28.9 48.7 3.4 (7.5)
5A0004 33.6 27.5 61.1 27.6 54.3 81.9 3.4 (7.5)
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
42
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
