YASKAWA A1000 Series User Manual

n
Flange Type Heat Loss Data
Table 2.19
Models 2A0169 and 2A0211, 4A0139 and 4A0165, and 5A0062 to 5A0099
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz)
HD (Fc =
<1>
)
Internal External Total Internal External Total
2A0169
200
380 1014 1394 306 816 1122 41 (90.2)
2A0211 473 1218 1691 378 976 1354 42 (92.4)
<1> Carrier frequency is set to 8 kHz in model 2A0169 and set to 5 kHz in model 2A0211.
Drive Model
Voltage
Class
Input Type
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz)
HD (Fc =
<1>
)
Internal External Total Internal External Total
4A0139
400 6-Pulse
534 1215 1749 416 908 1324 45 (99.0)
4A0165 668 1557 2225 580 1340 1920 46 (101.2)
<1> Carrier frequency is set to 8 kHz in model 4A0139 and set to 5 kHz in model 4A0165.
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz)
HD (Fc =
<1>
)
Internal External Total Internal External Total
5A0062
600
279 791 1070 335 1272 1607 45 (99.0)
5A0077 329 959 1288 379 1457 1836 45 (99.0)
5A0099 412 1253 1665 352 1267 1619 45 (99.0)
<1> Carrier frequency is set to 8 kHz in models 5A0062 and 5A0077 and set to 5 kHz in model 5A0099.
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
65
2
Mechanical Installation

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
