Flange Type Heat Loss Data
Table 2.21
Models 2A0360 and 2A0415, 4A0250 to 4A0362, and 5A0192 and 5A0242
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz)
HD (Fc =
<1>
)
Internal External Total Internal External Total
2A0360
200
894 2698 3592 783 2564 3347 108 (238)
2A0415 954 2672 3626 954 2672 3626 –
<1> Carrier frequency is set to 5 kHz in model 2A0360 and set to 2 kHz in model 2A0415.
Drive Model
Voltage
Class
Input Type
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz)
HD (Fc =
<1>
)
Internal External Total Internal External Total
4A0250
400 6-Pulse
803 2379 3182 715 2360 3075 106 (233)
4A0296 905 2448 3353 787 2391 3178 112 (246)
4A0362 1130 3168 4298 985 3075 4060 117 (257)
<1> Carrier frequency is set to 5 kHz in models 4A0250 and 4A0296, and set to 2 kHz in model 4A0362.
Drive Model
Voltage
Class
Heat Loss (W)
Wt. kg (lb)ND (Fc = 2 kHz) HD (Fc = 2 kHz)
Internal External Total Internal External Total
5A0192
600
769 2420 3189 648 2114 2762 117 (257)
5A0242 1131 3100 4231 896 2526 3422 117 (257)
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
70
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
