11.8 H: Terminal Functions
688 YASKAWA SIEPC71061723A YASKAWA AC Drive CR700 Technical Manual
■ H1-09: Terminal S9 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-09
(0406)
Terminal S9 Function
Selection
Sets the function for MFDI terminal S9.
F
(0 - 1FF)
■ H1-10: Terminal S10 Function Selection
No.
(Hex.)
Name Description
Default
(Range)
H1-10
(0407)
Terminal S10 Function
Selection
Sets the function for MFDI terminal S10.
F
(0 - 1FF)
■ H1-21: Terminal S1 Function Select 2
No.
(Hex.)
Name Description
Default
(Range)
H1-21
(0B70)
Terminal S1 Function
Select 2
Sets the second function for MFDI terminal S1.
F
(0 - 1FF)
Operates the function assigned to H1-01 [Terminal S1 Function Selection] and the function assigned to H1-21
simultaneously if the MFDI terminal S1 is turned ON.
When you set F, the function will be disabled.
■ H1-22: Terminal S2 Function Select 2
No.
(Hex.)
Name Description
Default
(Range)
H1-22
(0B71)
Terminal S2 Function
Select 2
Sets the second function for MFDI terminal S2.
F
(0 - 1FF)
Operates the function assigned to H1-02 [Terminal S2 Function Selection] and the function assigned to H1-22
simultaneously if the MFDI terminal S2 is turned ON.
When you set F, the function will be disabled.
■ H1-23: Terminal S3 Function Select 2
No.
(Hex.)
Name Description
Default
(Range)
H1-23
(0B72)
Terminal S3 Function
Select 2
Sets the second function for MFDI terminal S3.
F
(0 - 1FF)
Operates the function assigned to H1-03 [Terminal S3 Function Selection] and the function assigned to H1-23
simultaneously if the MFDI terminal S3 is turned ON.
When you set F, the function will be disabled.
■ H1-24: Terminal S4 Function Select 2
No.
(Hex.)
Name Description
Default
(Range)
H1-24
(0B73)
Terminal S4 Function
Select 2
Sets the second function for MFDI terminal S4.
F
(0 - 1FF)
Operates the function assigned to H1-04 [Terminal S4 Function Selection] and the function assigned to H1-24
simultaneously if the MFDI terminal S4 is turned ON.
When you set F, the function will be disabled.
■ H1-25: Terminal S5 Function Select 2
No.
(Hex.)
Name Description
Default
(Range)
H1-25
(0B74)
Terminal S5 Function
Select 2
Sets the second function for MFDI terminal S5.
F
(0 - 1FF)
