YASKAWA NX100 Instructions

8.6 Interference Area
8-60
8.6.4 Clearing the Interference Area Data
Operation Explanation
1 Select interference signal to
be cleared.
Select the desired interference signal number to be cleared using
the page key or by number input.
When selecting the desired interference signal number by num-
ber input, click on {PAGE} to input the desired signal number.
2 Select {DATA} under the
menu.
3 Select {CLEAR DATA}. The confirmation dialog box appears.
4 Select {YES}. All the data of the interference signal number are cleared.
PAGE
GO BACK
Yes
No
Initialize?
Short CutMain Menu
INTERFERENCE AREA
INTERFERENCE SIGNAL : 1 / 32
DATA EDIT DISPLAY UTILITY
AXIS INTERFERENCE
COMMAND POSITION
METHOD
CONTROL GROUP
CHECK MEASURE
PAGE

YASKAWA NX100 Specifications

General

Manufacturer	YASKAWA
Model	NX100
Operating Temperature	0 to 45°C
Humidity	20 to 80% RH (non-condensing)
Communication Interfaces	Ethernet
Safety Standards	ISO 10218-1
Power Supply	200-230V AC, 50/60Hz
Storage Temperature	60°C
